General Description

The LPW5208 is an integrated power switch for self-powered and  bus-powered  Universal  Series Bus (USB) applications. A built-in charge pump is used to drive the N-Channel MOSFET that is free of parasitic body  diode to  eliminate  any reversed current flow across the switch when it is powered off. Its low quiescent current (16μA) and small package (SOT23-5) is particularly suitable in battery-powered portable equipment.

Several protection functions include soft start to limit inrush current during plug-in, current limiting at 1500mA to meet USB power requirement, and thermal shutdown to protect damage under over current conditions.
